System Concepts Lab Measurements

The Bode 100 is used at the Regensburg University of Applied Sciences to perform several measurements at the system concepts lab



Check out the following documents that are guiding through the lab lessons:

This documents provides the students a quick overview on the Bode 100 and how to use it for Gain / Phase measurements:
Bode 100 Quickstart


This document deals with the theory of first and second order systems and their signal transfer functions.
Furthermore the stability of the systems is discussed and an introduction on SPICE simulation is given.
In the hands on section, the Bode 100 is used to measure the gain/phase of electronic circuits. Errors in the feedback path are evaluated using the B-WIT 100 injection transformer:
Lab 1: Analog 1st & 2nd order system



This document gives an insight on quantization noise, oversampling and delta sigma modulation. The Bode 100 is used for gain/phase measurements and in addition as a spectrum analyzer:
Lab 2: Sigma Delta Modulation



Questions & Feedback

We try to constantly improve our application notes and videos. To do so, we are happy to receive your valuable opinion on them. Therefore, please send us your comments and insights via the feedback form, which you can access via the button below.

Feedback

image-992
image-991
Prof. Dr. Martin Schubert is working at the Regensburg University of Applied Sciences in the electronics department. The Regensburg University of Applied Sciences offers several Bachelor, Master and postgraduate programs for about 7,000 students.
